| JAC HF1042 | |||||||||
| SPECIFICATION | |||||||||
| BASIC DESCRIPTION | |||||||||
| Model | HFC1042L4W | HFC1042L6W | HFC1042LD4W | HFC1042LD6W | |||||
| Emission Standard | Euro III | ||||||||
| Cabin / Seating Capacity | Single/3 | Double/5 | |||||||
| ENGINE | |||||||||
| Model | HFC4DA1-2B1 | ||||||||
| Type | In Line – 4 Ind-Cooler Turbocharged Diesel Common Rail |
||||||||
| Displacement (cc) | 2771 | ||||||||
| Compression Ratio | 17.5 | ||||||||
| Max Power (kw/rpm) | 110/3600 | ||||||||
| Rated Torque (Nm/r/min) | 240/2000-2200 | ||||||||
| TRANSMISSION | |||||||||
| Model | LC5T255M3 | ||||||||
| Gear Position | R 2 4 1 3 5 |
||||||||
| PERFORMANCE | |||||||||
| Max Speed (km/h) | 111 | 110 | |||||||
| Max Gradeability (%) | 38 | ||||||||
| BRAKES | |||||||||
| Brake System | Hydraulic Brakes | ||||||||
| TYRES | |||||||||
| Tyre Size | 7.00R16 / 205/75R17.5 | ||||||||
| DIMENSIONS | |||||||||
| Overall Dimensions (mm) (L*W*H) | 6055/1868/2154 | ||||||||
| Cargo Dimensions (mm) (L*W*H) | 4380/1770/400 | 3618/1770/400 | |||||||
| Wheelbase (mm) | 3360 | ||||||||
| Tread (Front/Rear) (mm) | 1440/1425 | ||||||||
| MASS DATA | |||||||||
| Curb Weight (kg) (BTM) | 2160 | ||||||||
| Max Load Capacity (kg) | 2840 | ||||||||
| Gross Vehicle Weight (kg) (BDM) | 5000 | ||||||||
| Min Turing Radius (m) | 6 | ||||||||
| CONFIGURATION | |||||||||
| Air Conditioner | ○ | ||||||||
| Power Steering | √ | ||||||||
| Pre-Heater | √ | ||||||||
| Wind Deflector | ○ | ||||||||
| Side Bumper | √ | ||||||||
| Rear Bumper | √ | ||||||||
| Power Assist of the Clutch | − | ||||||||
| Digital Radio | √ | ||||||||
| Exhaust Braking | − | ||||||||
| USAGE | |||||||||
 Box Van
 Concrete Mixer
 Cargo Truck
 Curtain Side Truck
 Tanker
 Cargo Crane
 Car Carrier
 Refrigerated Truck
 Dump Truck
 Garbage Truck
 Roll On Roll Off
 Aerial Platform
|
